Masterpiece® Triple Wall Oven 30'' Stainless Steel
MEDMCW31WS

1 / 0
Photo Nr. 1 of the product MEDMCW31WS
Photo Nr. 2 of the product MEDMCW31WS
Photo Nr. 3 of the product MEDMCW31WS
Photo Nr. 4 of the product MEDMCW31WS
Photo Nr. 5 of the product MEDMCW31WS
Photo Nr. 6 of the product MEDMCW31WS
Photo Nr. 7 of the product MEDMCW31WS
Photo Nr. 8 of the product MEDMCW31WS
Photo Nr. 9 of the product MEDMCW31WS
Photo Nr. 10 of the product MEDMCW31WS
Photo Nr. 11 of the product MEDMCW31WS
Photo Nr. 12 of the product MEDMCW31WS
Photo Nr. 13 of the product MEDMCW31WS
Photo Nr. 14 of the product MEDMCW31WS
Video Nr. 15 of the product MEDMCW31WS

Masterpiece® Triple Wall Oven 30'' Stainless Steel
MEDMCW31WS

$16,079.00
MSRP (CAD $), dealer may sell for less
Find a local Dealer
Find a local dealer in your vicinity

Masterpiece® Triple Wall Oven 30'' Stainless Steel
MEDMCW31WS

$16,079.00
MSRP (CAD $), dealer may sell for less
Find a local Dealer
Find a local dealer in your vicinity

Technical Overview

Overall Appliance Dimensions (HxWxD) (in)
61 3/16 x 29 3/4 x 24 1/2
Dimensions
1554x755x622 mm
Color
Stainless Steel

Highlights

Specifications

Total number of cooking modes cavity 1
36
Total number of cooking modes cavity 2
16
Location of second cavity
central
Location of third cavity
Bottom
Cooking Modes
Defrost, Air Fry, Rôtisserie, Proof, Convection, Microwave, Bake, Pizza, True Convection, Max Convection Broil, Convection Broil, Keep Warm
Cooking Modes Second Cavity
, Dehydrate, Large-area grill, Grilling with rotary spit, Dough proving setting, HotAir, Top/bottom heat, Convection Bake, pizza setting, Convection - fan only, Hot air grill, Convection Broil, Variable small-area grill, warming
Cooking modes - cavity 3
Dehydrate, Dough proving setting, Microwave, 3rd element convection, Warming Drawer
Cavity Capacity
4.5 Cu Ft
Second cavity capacity
3.7 Cu Ft
Cavity Capacity Third Cavity
1.9 Cu Ft
Rotisserie
Yes
Telescopic rails
Yes
Heating modes combinable with microwave function
Not applicable
Proof Mode
Yes
Included Accessories
1 x rotary spit, 1 x grid high, 1 x grid flat, 1 x temperature probe /upper, 3 x telescopic rack
Overall Appliance Dimensions (HxWxD) (in)
61 3/16 x 29 3/4 x 24 1/2
Dimensions
1554x755x622 mm
Required Cutout Size (HxWxD) (in)
60 3/4 x 28 1/2 x 23 1/2
Required cutout size (HxWxD)
724 x 1543 x 597.0 mm
Net Weight
302.000 lbs
Net Weight
137.2 kg
Cavity Capacity
4.5 Cu Ft
1 / 0
Photo Nr. 1 of the product
Photo Nr. 2 of the product
Photo Nr. 3 of the product
Photo Nr. 4 of the product
Plug type
no plug, fixed connection
Power Cord Length
60
Power cord length
152 cm
Volts
240/208 V
Watts
10200 W
Amps
40; 50/40 A
Rotisserie
Yes
Air Fry Function
Yes (Special accessory available separately)
True Convection
3D (even heat distribution on up to three levels)
Fast Pre-Heat
Yes
SoftClose® Door
Yes
Cleaning System
Self Clean
Cleaning system - secondary cavity
Self Clean
ADA Compliant
No
Sabbath Mode
Yes
Home Connect® WiFi-enabled
Yes
Home Connect® Features
Remote Diagnostics, Remote Monitoring and Control
